UV Curing Systems for Heidelberg
Seamless integration of Heidelberg's various series of offset printing presses with a high-precision paper feeding system and inline drying requirements. The power of the mercury lamps can be customized according to the press speed, with spectral peak wavelengths at 365nm that perfectly match Heidelberg UV ink absorption bands.
Structure & Compatibility:
Utilizing a specialized bracket design that accommodates the reserved space of Heidelberg drying units, requiring no modifications to the original airflow ducts, allowing installation within 2 hours without affecting the original infrared drying system.
🚀
Fast drying: Instantaneous curing at 120m/min speed, solving ink smudging and dot spreading.
💡
Energy optimization: Intelligent power adjustment interacting with CPC control, reducing power during standby.
UV Curing Systems for KBA
Customized development for KBA Rapida series offset presses to meet the demands of wide-format printing (maximum width of 1620mm) and ultra-high-speed operation (up to 20,000 sheets per hour).
Matrix-type Light Source:
Multi-lamp group parallel configuration combined with intelligent zoned light control, ensuring uniform intensity across the entire width.
Quick-install Design:
Customized bracket fits top space of drying units, supporting maintenance without stopping the press to minimize downtime.
UV Curing System for Roland
Customized for Roland 700 series and VersaUV series to meet high-precision multi-color registration and intelligent control requirements.
🎯
Laser Positioning: Uses laser distance measurement to reduce spacing errors and ensure precise alignment.
🎨
Color Management: Achieves color difference (ΔE) ≤ 1.5, accurately restoring print color saturation.
Plug-and-play modular design adapts to Roland's standard drying unit interfaces, supporting quick switching between light sources.
UV Curing System for Komori
Tailored for Komori Lithrone and GL series to meet requirements for stable platforms and environmentally friendly processes.
Lightweight Integrated Design: Uses aerospace-grade aluminum brackets, compatible with Komori drying unit top load-bearing structures and original exhaust systems.
Wide Color Gamut: Tailored for Color Sync management, using dual-banded mercury lamps for high-end color printing and luxury packaging.
UV Curing System for Mitsubishi
Designed for Mitsubishi Diamond and Apostle series with full servo drive systems and complex paper paths.
📈
Dynamic Tracking: Real-time monitoring of speeds up to 16,000 sheets/hour, adjusting lamp height for even curing on thick paper (600g/m²).
🌡️
Low-Temperature: Power adjustment (as low as 4kW) maintains surface temperatures below 45°C for heat-sensitive materials.
Supports integration with gloss and lamination units; drying and coating intervals are less than 1 second. Lamp lifespan is extended to over 3,000 hours.
UV Curing Systems for Ryobi
Optimized for packaging printing where Leafy offset presses excel. The system supports rapid curing, enhancing ink adhesion on rough surfaces like corrugated cardboard.
🛠️
Modular Installation: Quick adaptation without altering existing electrical circuits or mechanical structures.
♻️
Compatibility: Works with the original ink circulation system to minimize production loss.
Frequently Asked Questions
How long does the installation take?
The specialized bracket design allows for installation within approximately 2 hours without modifying original airflow ducts.
What is the typical lifespan of the mercury lamps?
Our advanced technology extends lamp lifespan to over 3,000 hours, which significantly surpasses the industry average.
Can these systems handle heat-sensitive substrates?
Yes, our low-temperature curing technology maintains surface temperatures below 45°C, preventing deformation of sensitive materials.
Is it compatible with wide-format offset presses?
Absolutely. We offer matrix-type light source layouts that support widths up to 1620mm with uniform intensity coverage.
Does the system support high-speed production?
Yes, the systems are designed to match press speeds of up to 20,000 sheets per hour or 120m/min for instantaneous ink curing.
Are the systems compatible with original press control systems?
Yes, they are designed to interact with systems like Heidelberg's CPC or Roland's ColorTronic for intelligent power adjustment.
